The PB-1760W，a remarkable new generation monitor,supports 3D-LUT color calibration,3Gbs SDI 4:4:4 12Bit signals,no compression,no loss, more perfect display of image,these monitors are provided with waveform,vector scope,histogram and other professional broadcast features,suitable for most demanding application of image quality of high-end broadcast shooting,editing and production. Product Highlight

• 3″ 1920×1080 Resolution
• 12-bit video processing performance
• 3D Lut color calibration,and color space selection:REC709,EBU,SMPTE-C,DCI-P3,USER1,USER2,USER3
• Gamma selection: 1.0~2.8 and C-Log,S-Log etc
• 3G/HD/SD-SDI Input&Loop through
• Composite&Component Input
• Support 3G-SDI, 4:4:4 signals (SMPTE 425M A/B)
• Dual Pictures (PIP/PBP) for 2 SDI Signals
• PIP/PBP（Size / Position Adjustable,Alpha Blending( PIP )）
• PIP/PBP in rapid swap
• Waveform(Y/CbCr,Wide Type,Waveform Alarm)
• Vectorscope (Vector Scale 75%/100%)
• Histogram (Y / RGB)
• Pixel Measure(Y/R/G/B Values Comparision)
• H Flip
• ×9 Zoom
• H/V Delay
• Focus Assist
• Blue Only/Mono
• False Color/Zebra
• 8ch Embedded Audio Meter(H/V)
• Full scan/Over Scan
• Color Temperature(9300K, 6500K, 5600K,User)
• UMD Support(ID/Positiion/Color/User Rename)
• TimeCode（VITC1,VITC2,LTC）
• PAL/NTSC/SECAM
• OSD Setting
• Various Marker
• Image Size Selectable
• RS-232/Ethernet for Remote Control
• Two power supply ways: DC IN and AC IN
• 19″ Standard Rackmount
• Tally
