The PB – 1751W, both AC and DC power support, full video formats including 3Gbs SDI 4:4:4 signals and professional features. Dual SDI signals display of PIP/PBP, custom setting UMD, select table RS-232/RS485 remote control with self-innovative pixel measurement function and more. All these advanced features make it a premium monitoring solution for rack-mount, desktop, post production, broadcast field use etc. Product Highlight

• 17″ 1366×768 Resolution
• 3G/HD/SD-SDI Input & Loop through
• Composite & Component Input
• Dual Pictures (PIP/PBP) for 2 SDI Signals
• PIP Size / Position/Alpha Blending Adjustable
• PIP/PBP in rapid swap
• Support 3G-SDI, 4:4:4 signals (SMPTE 425M A/B)
• Waveform (Y/CbCr, Wide Type, Waveform Alarm)
• Vectorscope (Vector Scale 75%/100%)
• Histogram (Y / RGB)
• Pixel Measure(Y/R/G/B Values Comparision)
• Picture Flip
• ×9 Zoom
• H/V Delay
• Focus Assist
• Blue Only/Mono
• False Color/Zebra
• 8ch Embedded Audio Meter (H/V)
• Full scan/Over Scan
• Color Temperature(9300K, 6500K, 5600K, User)
• UMD Support(ID/Positiion/Color/User Rename)
• OSD Setting
• TimeCode （VITC1, VITC2, LTC）
• Various Marker
• Image Size Selectable
• Two power supply ways: DC IN and AC IN
• RS-232/RS-485 Remote Control
• 19″ Standard Rackmount
• Tally
